Specs
Maverick HD Engine Options
- Kawasaki
- 4200/4800 - 726cc, 22hp Air-Cooled 90° V-Twin FX691
- Kawasaki
- 5400/6000 - 726cc, 23.5hp Air-Cooled 90° V-Twin FX730
- Honda
- 4200/4800/5400/6000 - 688cc, 24hp Air Cooled V-Twin GXV
- Kohler
- 4200/4800/5400/6000 - 747cc, 25hp Air Cooled V-Twin Command Pro EFI ECV749
Maverick HD Dimensions
- Cutting Widths
- 4200 - 42"; 4800 - 48"; 5400 - 54"; 6000 - 60"
- Weight
- 4200 - 998 lbs.; 4800 - 1,023 lbs.; 5400 - 1,048 lbs.; 6000 - 1,073 lbs.
- Overall Height / Length
- 49"/80"
- Chute Up / Chute Down Width
- 4200 - 47"/56"; 4800 - 54"/61"; 5400 - 58"/67"; 6000 - 64"/73"
Maverick HD Features
- Suspension
- E-Z Ride® Patented Compression Rear Suspension with Independent Front Suspension Rails
- Transmission
- 3400 Hydro-Gear® 12cc Integrated Transaxle
- Deck Thickness
- 3/16" or 7-Gauge Thick Solid Steel
- Cutting Height
- 1.5" - 4.5" with Deck Height Control System
- Lift & Height Adjustment
- Foot-Assist Manual Lift with Dial-Style Height Adjustment. Optional Electric Lift.
- Rear Tires / Front Tires
- 4200/4800 - 23x9-12 Reaper® / 13x6.5-6 Smooth No Flat Front
5400/6000 - 23x11-12 Reaper® / 13x6.5-6 Smooth No Flat Front - Fuel
- 13 Gallons, Unleaded Gasoline
- Ground Speed (Forward)
- Up To 9 mph
